Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SURELION ShuMing
  • Model Number: CD60
  • Type: Polyester Film Capacitor
  • Application: AC / Motor
  • Package Type: Surface Mount
  • Capacitance: 100-500uf
  • Rated Voltage: 250vac
  • Operating Temperature: -40~70
  • color: blue
  • case: aluminum
  • terminal: pin

Packaging & Delivery

Packaging Details standard of export carton
Delivery Time 20 days after receive deposit

Product Description

CD60 Motor Start  Capacitor

Features and Use:

CD60 series aluminum electrolytic capacitor for starting A.C. motor are made of by the aluminium foil bar as the poles,alumina as dielectric, mushy state electrolyte and all of devices in one compact unit which can be sealed separately in bakelite or ABS case.

The connection types are of dual quick-connect terminal, wire  and cable type.

The specific type of capacitors with high electrical characteristics are widely used in single phase A.C. motors with rated voltage of 110V-330V and the frequency of 50Hz - 60Hz to get high rotary torque at low starting current, and also the motor at a lower starting current under high torque.

Options available at an added cost include bleeder resistors.

This type capacitor is suitable used in single phase A.C. motors, compressor, etc.



PRODUCT PICTURE:





Products Technical Data

Material

Start Capacitor.

Usage

Micro water pump, cleaning machine,

washing machine, and single-phase water pump motor.

Climate Types

40/70/21.
Capacitance Range 21-1280uf

Voltage Rating

110VAC to 330VAC

Capacitance Variance

0~+20%
Dielectric Material: aluminium foil
Case Material: bakelite or ABS case

Terminal

2 to 4 quick-disconnect, Wire, Cable and with screw

Testing voltage

Between leading-out 2UR, 10S no breakdown.

Between leading-out end and shell: 2200VAC, 10S no breakdown .

Insulation resistance

Between leading-out ends:≥3000MΩ.μF .

Between leading-out end and shell: ≥1000MΩ.

Loss tangent

tgδ< 0.10   tgδ< 0.15   (100Hz)

Specifications

Can be supplied according to the customers' special requirement.



Trade Information

MOQ

100pcs per item

Place of Origin

Wenling China

Price item

EXW,FOB,CNF,CIF

Payment terms

30% T/T in advance, balance paid against copy of B/L.T/T ,L/C

Shipment

By Express, By Sea, by Air

Delivery time

5-7 days for sample,15-20 days for mass production
Sample time5-7 days
